Design, Supply and Install and Commission 3 X 30m3/hr Portable Demineralised Water Treatment Plant
The project calls for design, supply, installation, commissioning, and training of site staff, for a 3 X 30m3/hr portable demineralised water treatment plant to be delivered to Tuanku Ja'afar Power Station, Port Dickson, Malaysia (TJPS). The plant is entirely portable. Tenderer shall take into consideration the feed water quality and required treated water quality of the plant. The total gross throughput shall be > 1900 m3/day.The designed ion-exchange process comprises a cation exchanger, anion exchanger, followed by a polishing mixed bed.
Relocation of Existing Electrochlorination Plant From Port Dickson Power Plant to Paka Power Plant
Severn Trent De Nora is the original equipment manufacturer of electrochlorination system at TNB Port Dickson. We managed to dismantle the existing system from TNB PD and relocate it to TNB Paka within stipulated time frame. The scope includes supply and erection of new transformer rectifiers and piping systems. The electrochlorination plant is still in operation till to date.
Installing a Suspended Access Platform to a Flue, Water Wash of the Flue, Inspection, Removal of the top 6m of a Brick Section and Re-building of the Brick Section
The repair scheme consisted of the renewal of upper 6m brickwork and external insulation of flue Sections 1 through to 8 in each of the three flues by installing a DOSH approved suspended platform. The job scope includes water washing of the flu internal.
ElectroChlorination Plants generate sodium hypochlorite from seawater using an extensively field-proven electrochemical process. ECP systems are the standard and preferred Electrochlorinations system for biofouling control in offshore and marine biofouling control as well as power and coastal applications. We have our in-house tea who can perform installation of the systems, refurbishment of the systems and maintenance of the systems. Our team consists of well trained and experienced engineers to be the prime contact points of plant owners for ECP related issues.
Complete replacement of 3 numbers of 120m3/hr Sodium Hypochlorite injection pump and 3 lines of existing 6" PVC with FRP coated pipeline with ABS pipelines. The length of one dosing line from ECP to the Pump house is estimated about 780 meter. The entire ABS pipes were connected with plain socket and for every 35~50 meter straight pipeline has been install with single arc expansion joint to provide further expansion or movement on the pipeline due to thermal expansion.
The project specification called for design, install, test and commission cathodic protection system for fuel unloading jetty at Stesen Janaelektrik Sultan Iskandar, Pasir Gudang. Contained herein is a proposed Cathodic Protection design for the steel piles of the mooring dolphins and jetty piles. Cathodic Protection system was designed for 8 years design life. Sacrificial anode cathodic protection system has been used. There are altogether 99 piles on the approached bridge, jetty and walkway support. Consisting of 75 nos. of 750 mm diameter piles and 24 nos. of 600 mm diameter piles. To ensure better welding contact between the anodes and the piles, our anodes come with steel channel at both ends.
 |
|
Cathodic Protection System For Fuel Unloading Jetty |
 |
|
Inspection of Reference Electrode |
 |
|
Inspection of Reference Electrode |
 |
|
Refurbishment of CP Transformer Rectifier |
| Seq. | Name | |
|---|---|---|
| 1 | Relocation of electrochlorination plant Port Dickson Power Plant to Paka Power Plant Terengganu. | |
| 2 | To design, install and commissioning portable demin water plant at Port Dickson Power Plant | |
| 3 | Rehabilitation of electrochlorination plant for Kapar Energy Ventures Sdn Bhd. | |
| 4 | Supply, supervise and install guillotine dampers for unit 3 & 4 MILL isolation for Kapar Power Station | |
| 5 |
| |
| 6 | Dismantle, supply, install and commission fully assembled electrolyzer for electrochlorination plant for Manjung Power Station. | |
| 7 | To design, supply and fabricate of butterfly valves, actuators and expansion joint for pltu 1 Jawa Tengah 2 x (300-400mw) coal - fired power plant at Rembang, Jawa Tengah, Indonesia (Zelan Holdings (M) Sdn Bhd) | |
| 8 |
| |
| 9 | To design, repair and maintenance chimney for at TNB Janamanjung unit 1,2 &3. | |
| 10 | Design, supply, install & commission MIL KSB Control Valve at Segari Power Plant- Lumut | |
| 11 | Multiflue Chimney Repair Works at TNB Janamanjung | |
| 12 | Supply, install & commission HPU (Bottom Ash Hopper Silo Gate Valve) at TNB Janamanjung | |
| 13 | Service & supervise boiler feed pump at Kapar Power Plant | |
| 14 | Design, install & commissioning minimum recirculating boiler feed water stop valve at Perlis Power Plant | |
| 15 | Supply, install, commissioning boiler blow down and station ash pump at TNB Janamanjung | |
| 16 | Installation & commissioning of various pump at Kapar Power Plant | |
| 17 | Supply, install & commissioning Tricentric Butterfly Valve c/w electric actuator | |
| 18 | Replacement of existing sodium hypochlorite injection pipeline at Kapar Power Plant | |
| 19 | Installation & commissioning of various pumps at TNB Janamanjung | |
| 20 | Supply various sizes boiler tubes (t91, a210, f22,) at Kapar Power Plant | |
| 21 | Supply HP circulation pump to Connaught Power Station. | |
| 22 | Supply boiler feed pump to Connaught Power Station. | |
| 23 | Supply boiler feed pump booster pump to Manjung Power Station. | |
| 24 | Supply spare parts for condenser extraction pump to Manjung Power Station. | |
| 25 | Supply BFP booster pump to Kapar Power Plant. | |
| 26 | Supply high pressure sluice pump shaft and accessories for kapar power station | |
| 27 | Supply high pressure sluice pump spare parts for Kapar Energy Ventures Sdn Bhd | |
| 28 | Supply HP sluice pump bearing housing for Kapar Energy Ventures Sdn Bhd. | |
| 29 | Supply spare parts for Hopkinson bled steam non return valves to Manjung Power Station. (Manufactured By Weir Valves & Controls UK) | |
| 30 | Supply spare parts for Hopkinson Check Valve to Manjung Power Station. | |
| 31 | Supply valve bled steam NRV (cold reheat) complete without actuator to Manjung Power Station. | |
| 32 | To supply spare parts for GF3 cold reheat non return valve overhaul at Kapar Power Station. | |
| 33 | Supply of cold reheat non return valve for Kapar Energy Ventures Sdn Bhd. | |
| 34 | Supply boiler feed pump spare parts for Kapar Power Plant | |
| 35 | Supply boiler feed pump spare parts for Manjung Power Station. | |
| 36 | Supply Hopkinsons Valve Spare Parts for TNB Janamanjung - on going | |
| 37 | Supply of KSB submersible pumps complete with motors for TNB | |
| 38 | Supplied various parts for GE turbine frame 9e at Pahlawan Power Plan | |
| 39 | Supplied bearing oil cooler- shell & tubes at Manjung Power Plant- Boiler Feed Pump | |
| 40 | Supplied boiler feed pump cartridge to Kapar Power Plant | |
| 41 | Supplied condensate extraction pumps to Manjung Power Station | |
| 42 | Dismantle, install & commissioning 2 nos of heat exchanger- shell & tubes at Kapar Power Plant Ph 3 | |
| 43 | Supplied various spare parts for booster & boiler feed pump for Kapar Power Plant | |
| 44 | To supply & apply polyurea coating on the steel structure- corrosion mitigation at Kapar Power Plant | |
| 45 | Repair & service hp turbine bypass valve at Perlis Power Plant | |
| 46 | To replace auxially shell & tubes heat exchangers to Kapar Power Plant PH 1 | |
| 47 | To replace shell & tubes heat exchangers for turbine oil cooler to Pahlawan Power Plant | |
| 48 | Install 23 nos of Sanilec Electrolysers at Port Dickson Power Plant (year 2012) | |
| 49 | To supply, install and servicing IPBS at TNB Janamanjung | |
| 50 | To supply, and install 10 nos of Sanilec Electrolyers at Port Dickson Power Plant - year 2013 | |
| 51 | To design, install and commissioning portable demin water plant at Port Dickson Power Plant | |
| 52 | To supply, testing & commissioning 1 no of 412 KVA, Transformer at TNB Port Dickson - Year 2012 | |
| 53 | To dismantle, install & commissioning 2 nos of Transformer rectifier (5200 Amp @ 110 DC) at Kapar Power Plant Ph 2- Year 2013 | |
| 54 | To refurbished 30 nos of SANILEC cells Stream A at Janamanjung Power Plant- Year 2014 | |
| 55 | To supply Transformer Rectifier spare parts- Dyanapower at TNB Port Dickson - Year 2014 | |
| 56 | To supply various type of spare parts for Cylde Burgnmann sootblower at Kapar Power | |
| 57 | To supply various type of spare parts for Cylde Burgnmann sootblower at Tanjung Bin Power Plant - Year 2009-2010 | |
| 58 | To supply rubber expansion joint - TPSC (Prai Power Plant) | |
| 59 | To fabricate steel structure at TNB Port Dickson Ph 2 - TPSC | |
| 60 | To replace, supply and install various type of idler and pulley at Kapar Power Plant - LTSA for 2 years | |
| 61 | To dismantle, install, test and commissioning 3.3 KV CONVEYOR & CRUSHER MOTOR | |
| 62 | To dismantle, supply, install and commissioning 1 set Rotor for Induced Draft Fan at Kapar Power Plant- Unit 6 | |
| 63 | To dismantle, supply, install and commissioning 1 set Rotor for Induced Draft Fan at Kapar Power Plant- Unit 5 | |
| 64 | To replace, supply and install various type of idler and pulley at Kapar Power Plant - Coal Unloaders | |
| 65 | Supply, refurbish, and install 30 nos of Sanilec Electrolysers at Manjung Power Plant - Stream 1 | |
| 66 | Supply, refurbish, and install 30 nos of Sanilec Electrolysers at Manjung Power Plant - Stream 2 | |
| 67 | Cooling Water Pipe Line Work - Prai Combined Cycle Gas Turbine Power Plant (Malaysia) | |
| 68 | To supply manpower & Machinery to HSL (Singapore) | |
| 69 | Installation of 508 nos. Of Precast, Pre stressed Concrete Spun Piles for the Construction of new Bulkhead, Wharf at Pulau Indah, Malaysia-To supply manpower & Machinery to HSL(Singapore) | |
| 70 | On Going- Offshore and onshore work scope for Track 3B- Super Critical Power Plant- Malaysia- To supply manpower & Machinery to HSL (Singapore) | |
| 71 | To replace, supply and install various type of idler and pulley at Kapar Power Plant - LTSA for 2 years (2013-2015) | |
| 72 | To dismantle, install, test and commissioning 3.3 K CONVEYOR & CRUSHER MOTOR | |
| 73 | To replace, supply and install various type of idler and pulley at Kapar Power Plant - Coal Unloader | |
| 74 | To replace, supply and install various type of idler and pulley at Kapar Power Plant - Coal stacker reclaimer | |
| 75 | To replace, supply and install bucket for coal unloader at Kapar Power Plant | |
| 76 | Supply, Install, Commissioning Boiler Blow Down and station Ash Plant at TNB Jana Manjung | |
| 77 | Design, supply and installation of 5 years ash pond run off forwarding pumps for coal and ash- TNB Jana Manjung | |
| 78 | Design, supply and installation of 5 years clean rain water pump for coal and ash- TNB Jana Manjung | |
| 79 | To replace, supply and install conveyor belt at Kapar Power Plant | |
| 80 | Structure repair of the existing stacker reclaimer B at Kapar Power Plant | |
